Buchi E-800 - Installing One Protection Shield (Extraction Glass Chamber ECE Only); Preparing the Condenser

5 | Installation BÜCHI Labortechnik AG
40/88 Operation Manual UniversalExtractor E-800
u Put the front protection shield on both sides
into the front slot at the same time.
5.16.2 Installing one protection shield (Extraction glass chamber ECE only)
u Hold the protection shield on both sides at the
point indicated.
u Put the protection shield on both sides into the
front slot at the same time.
5.17 Preparing the condenser
NOTICE
Risk of broken parts by using tools
Using tools for preparing the instrument can break parts.
u Tighten all parts with your hands.
