BÜCHI Labortechnik AG Installation | 5
Operation Manual UniversalExtractor E-800 41/88
NOTICE!Make sure that the lips of the sealing
show in the direction of the glass.
u Put the sealing on the bottom of the con-
denser.
u Attach the solvent connection nut to the con-
denser.
u Connect the solvent collector tube.
u Put the condenser in the condenser rack.
u Secure the condenser with the flange lock.
