28
Start-up
Type ME43
AdressmappingforEtherCAT:
EtherCAT
Create a gateway conguration
EtherCAT data
EtherCAT product code
EtherCAT revision
#xFDF9
#x00010002
Addressing
Automatic EtherCAT addressing
NextCancelBack
Product code of the EtherCAT device, has to be a number, e.g. 12345678
EtherCAT revision of the device. Has to be a 8-digit hex-number and start with #x,...
Start
Reset device
Cyclic Name Index SubIndex
EVA_POS 0x2540 0x01
EVA_NamurStatus 0x2541 0x01
EVA_CMDdigital 0x2500 0x01
Device Status NamurNE107 0x2004 0x01
Control Word 0x3C32 0x01
Fieldbus-specicdevicedataandaccessdata
Automatic EtherCAT addressing
Start: Perform automatic EtherCAT addressing again
Resetdevice: Resets the values
Overview of EtherCAT addressing
Figure 14: Gateway conguration; Adress mapping EtherCAT
