Page #449 background imageLoading...
Page #449 background image
Setting Item Description, Instructions
GL2
Settings
Line &
Pen
Manag-
er
Smoothing
If you choose Smooth
ThickenFineLines Select On to print fine lines more distinctly.
AdjustFaintLines If fine lines are printed in colors that do not match the col-
ors of other shapes, selecting Off may help produce the
expected results. However, lines in some colors may ap-
pear broken.
Ln wdth correct Corrects by using a correction value that specifies the pen
width.
You can configure Black/gray and Color for each group.
The specified range is -20 to +20.
Proces-
singOp-
tion
Warning Select On to have any GL2-related warnings displayed.
On-the-Fly Selecting On will start printing jobs sooner if you are print-
ing only HP RTL print jobs and printing would not start un-
til later. However, images may be incomplete in some ca-
ses, so be sure to check the printing results.
Detect img size Sets the method of deciding the region to output in order
to print efficiently while avoiding missing images.
If Off is selected and the data contains image range infor-
mation, the image range information is followed.
If Off is selected and the data does not contain image
range information, a size with the maximum roll paper
width of the printer for the width and 1.5 times the maxi-
mum roll paper width for the length is used.
If Command priority is selected and the data contains
image range information, the image range information is
followed.
If Command priority is selected and the data does not
contain image range information, the detected minimum
image area is used.
If Detected size is selected, the detected minimum image
area is used.
GL2 Set Print Print GL2 settings information.
Inter-
face
Setup
EOP Timer Specify the timeout period before cancellation of print jobs
that cannot be received by the printer.
TCP/IP IPv4 IPv4 Mode Choose whether the printer IP address is configured auto-
matically or a static IP address is entered manually.
Proto-
col
DHCP Specify the protocol used to configure the IP address au-
tomatically.
BOOTP
RARP
IPv4
Settings
IP Address Specify the printer network information when using a stat-
ic IP address.
Enter the IP address assigned to the printer, as well as
the network subnet mask and default gateway.
The value that was automatically configured is displayed if
you have set IPv4 Mode to Automatic.
Subnet Mask
Default G/W
DNS
Settings
DNS Dync update Specify whether DNS server registration is updated auto-
matically.
Pri. DNS SrvAddr Specify the DNS server address.
Sec. DNS SrvAddr
iPF830
Menu Settings
User's Guide
Control Panel Printer Menu
449
