Page #450 background imageLoading...
Page #450 background image
Setting Item Description, Instructions
Inter-
face
Setup
TCP/IP IPv4 DNS
Settings
DNS Host Name Specify the DNS host name.
DNS Domain Name Specify the DNS domain name.
IPv6 IPv6 Support Specify whether to connect via IPv6.
IPv6 StlessAddrs Specify whether a IPv6 stateless address is used.
DHCPv6 Specify whether DHCPv6 settings are used.
DNS
Settings
DNS
Dync
update
Statefull
Addr
Specify whether DNS server registration is updated auto-
matically.
State-
less
Addr
Pri. DNS SrvAddr Specify the DNS server address.
Sec. DNS SrvAddr
DNS Host Name Specify the DNS host name.
DNS Domain Name Specify the DNS domain name.
Ether-
net
Driver
Auto Detect Specify the communication method. To apply your
changes, choose Register Setting.
Choose On for automatic configuration of the LAN com-
munication protocol. Choose Off to use settings values of
Comm.Mode and Ethernet Type.
Comm.Mode Choose the LAN communication method.
Ethernet Type Choose the LAN transfer rate.
Spanning Tree Choose whether spanning-tree packets are supported
over the LAN.
MAC Address Indicates the MAC address.
Interface Print Print interface settings information.
Return Defaults Choose OK to restore Interface Setup settings to the de-
fault values.
System
Setup
Sleep Timer Specify the period before the printer enters sleep mode.
Shut Down Timer Sets the time until the printer turns off automatically. If no
operations are performed on the printer for the duration of
the time set in Shut Down Timer after entering Sleep
mode, the printer automatically turns off.
Buzzer Choose On for the buzzer to sound once for warnings and
three times for errors.
Contrast Adj. Adjust the Display Screen contrast level.
Date &
Time
Date Set the current date.
Time Set the current time. Available only if the Date setting is
specified.
Date Format Specify the date format.
Language Specify the language used on the Display Screen.
Time Zone Specify the time zone. Time zone options indicate a main
city in this time zone and the difference from Greenwich
Mean Time.
Length Unit Choose the display unit for length. Change the unit dis-
played for the remaining amount of roll paper, Tot.Print
Area, and so on.
Detect Mismatch Specify printing behavior if the type and size of paper
specified in the printer menu does not match the type and
size in the printer driver.
Menu Settings
iPF830
User's Guide
Control Panel Printer Menu
450
