Canon imagePROGRAF iPF830 User Manual

Setting Item Description, Instructions
System
Setup
Detect Mismatch Choose Pause to have printing paused under these cir-
cumstances. Choose Warning to continue printing after
notification. Choose None to continue printing without no-
tification. Choose Hold Job to store jobs with mismatched
types and sizes of paper on the printer hard disk, in a print
queue awaiting processing. (See "Using the Printer Hard
Disk.") ➔P.513
Paper
Size Ba-
sis
Sht Selection 1 If sheet size detection is activated, choose whether ISO
A3+ or 13"x19"(Super B) is applied when a sheet of an
intermediate size is detected.
Sht Selection 2 If sheet size detection is activated, choose whether ISO
B1 or 28"x40" (ANSI F) is applied when a sheet of an in-
termediate size is detected.
Keep Paper Size Choose On to use the paper size setting as the basis for
printing instead of other settings. The margin setting of the
printer menu will be used instead of the margin setting of
the printer driver if the latter is smaller, which may prevent
text or images in the margin from being printed.
Choose Off to give priority to margin settings. The larger
value is used if the margin specified in the printer driver
does not match the margin in the printer menu.
TrimEdge Reload Specify whether to trim the leading edge of the currently
retracted roll when the roll is advanced. Cut the edge if
you are concerned about any marks left on the roll when
the roll is left in the retracted position.
Specify On to have rolls cut when printing begins after
Sleep mode or when the power is restored. Selecting Au-
tomatic will trim the edge when the roll has been in the
retracted position for two days or more.
Rep.P.head Print If you have selected On, the adjustment pattern is printed
after replacing the Printhead and Printhead adjustment is
performed. (See "Automatic Adjustment to Straighten
Lines and Colors.") ➔P.550
Nozzle Check In Frequency, specify the timing for automatic checks of
nozzle clogging. Choose Standard to have the printer ad-
just the timing for checks based on the frequency of noz-
zle use. Choose 1 page to check once per page. Choose
10 pages to check once per 10 pages. Choose Off to not
execute check.
If On is selected in Warning, a warning may be displayed
on the Control Panel depending on the result of the nozzle
check.
iPF830 Menu Settings
User's Guide
Control Panel Printer Menu
451

Canon imagePROGRAF iPF830 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Minimum line width	0.02 mm
Number of power supply units	1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az
Media thickness	0.07 - 0.8 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll length	18 m
Media width (sheets)	1117.6 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
JIS B-series sizes (B0...B9)	B0, B2
Display	LCD
Product color	Black, Grey
Storage media	HDD
Internal storage capacity	320 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Power supply	190 W
Power consumption (off)	0.5 W
Power consumption (standby)	5 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	975 mm
Width	1893 mm
Height	1144 mm
