COPYRIGHT © 2000 CANON INC. 2000 2000 2000 2000 CANON iR5000/iR6000 REV.0 JULY 2000
CHAPTER 2 MAIN CONTROLLER
2-1 S
1. Basic Operations
1.1 Functional Construction
The machine may be divided into the following functional blocks; the controller block is
shaded in the diagram:
F02-101-01
Control
panel
Printer unit
Main controller PCB
Reader unit
Hard disk drive
Accessory
boards
Controller block
Image Processing System
