CHAPTER 8 PAPER DECK
8-6 P
1.2.3 Sequence of Operations (pickup from the deck)
F08-102-02
INTR
LSTR
STBY
Deck main motor
(M101)
Deck pickup clutch
(CL102)
Deck pickup roller
releasing solenoid (SL101)
Deck pickup sensor
(PS101)
Deck feed sensor
(PS106)
SCAN
PRINT
Start key
ON
