CTR9 Car-O-Liner Group AB
49023, EN - rev. 4, 2020-01 33
3.9 C-Tong transformer gun
The C-Tong on the CTR9 features transformer gun technology for
greater working range, and includes a number of features:
1. Rotating handle
2. Trigger button
3. Rotating attachment for Support arm
4. Cylinder electrode
5. Yoke electrode
6. Electrode caps
7. Standard electrode yoke, 80 mm throat depth, water cooled
8. Locking lever for electrode yoke
9. Cooling liquid hoses for electrode yoke
10. Button for handle rotation
11. Transformer
12. Connector for Multi Function Gun control cable
13. Safety knob for electrode yoke release
14. LED indicators
Figure 3.2 C-Tong transformer gun
