Car-O-Liner Group AB CTR9
74 49023, EN - rev. 4, 2020-01
6.6 Using edge welding caps
Recommended start setting value when using edge welding cap (part no
45785) in standard mode is CURRENT/kA: 6.0 and TIME/ms: 500 (Weld
parameters may vary depending on sheet thickness).
Attention: If the welding spots are placed on the edge of the heat moulded
metal sheets (see picture above), the metal sheets joints will be altered by the
increased temperature which will affect collision characteristics in a negative
way.
To avoid this, the welding spots must be placed as far inward as possible.
With edge welding caps, the OEM repair manual demands for the a-measure
(see picture above) will be achieved.
