4.5.3 Changing the C-Tong electrode caps
Change the electrode caps by following the instructions below:
1. Electrode cap must be changed BEFORE the rounded tip becomes
flat. The standard cap radius is R15.
2. To remove the old electrode caps, use for example locking pliers.
Lock the tong and knock it hard.
3. To fit the new caps, place a welding tong between caps
and hammer them into position.
