Car-O-Liner Group AB CTR9
54 49023, EN - rev. 4, 2020-01
3. To remove the yoke electrode [a], release the hex/allen screw [b]
and pull out the electrode.
When inserting a new electrode, fit flat side of the electrode brim
to the yoke edge [c].
IMPORTANT! All straight electrodes have an inner tube that must be
fitted to provide sufficient cooling.
WARNING! The tools or electrodes may be hot. Risk for burning injuries.
Yoke
electrode
