Car-O-Liner Group AB CTR9
62 49023, EN - rev. 4, 2020-01
4.5.5 Changing and aligning the A-Tong electrodes
Change the A-Tong electrodes by following the instructions below:
1. Release the two locking screws and detach the electrode.
IMPORTANT! After electrodes are changed they must be aligned to
maintain optimal performance.
2. Align the electrodes (lockings screws released)
by adjusting them in height and for rotation.
To Next Page
