6.10.11 Carbon rod and stamp electrode shrinking
Carbon rod is a multi-function gun application for shrinking metal. Use rod
for larger area and stamp electrode for smaller area. (Break off carbon rod to
desired length.)
1. Select "Carbon rod" tool by pressing the "up/down" button.
2. Set current.
Lock nut
Carbon rod
Lock nut Stamp electrode
