CTR9 Car-O-Liner Group AB
49023, EN - rev. 4, 2020-01 63
4.5.6 Changing the A-Tong electrode caps
Change the electrode caps by following the instructions below:
1. Electrode cap must be changed BEFORE the rounded tip
becomes flat. The standard cap radius is R15.
2. To remove the old electrode caps, use for example a welding tong.
3. To fit new caps, gently hammer them into position with the
locking tong.
