Car-O-Liner Group AB CTR9
90 49023, EN - rev. 4, 2020-01
Changing the single spot electrode
To change the single spot electrode:
1. Make sure that the elctrode holder is fitted correctly to the multi-
function gun with the lock nut fully tightened.
2. Grip the electrode with a set of pliers.
Turn the pliers and the electrode back and forth to loosen the
electrode from the electrode holder.
3. Remove the used electrode from the holder.
4. Place a new electrode into the electrode holder. This can be done by
hand or by knocking it gently with a small hammer.
NOTE: Do not loosen the electrode by hitting it. This could damage either
the electrode, the electrode holder or the multi-function gun.
WARNING! The tools or electrodes may be hot. Risk for burning injuries.
