62-11640 5–20
HIGH ENGINE TEMP SHUT-
DOWN
YES / NO YES = When the 00012 HIGH COOLANT TEM-
PERATURE alarm has been activated three times in
the last two hours of engine operation 00021 TECH-
NICIAN RESET REQUIRED alarm will be activated.
NO = When the 00012 HIGH COOLANT TEMPERA-
TURE alarm has been activated three times in the
last two hours of engine operation the 00021 TECH-
NICIAN RESET REQUIRED alarm will not be acti-
vated.
ENGINE OIL PRESS SHUT-
DOWN
YES / NO YES = When the 00011 CHECK ENGINE OIL
PRESSURE alarm has been activated three times in
the last two hours of engine operation the A00021 −
“Technician Reset Required“ alarm will be activated.
NO = When the 00011 CHECK ENGINE OIL PRES-
SURE alarm has been activated three times in the
last two hours of engine operation the A00021 −
“Technician Reset Required“ alarm will not be acti-
vated.
FUEL LEVEL SENSOR YES / NO NO = There is no Fuel Level Sensor installed in the
fuel tank.
YES = A Low Fuel Level Sensor is installed in the fuel
tank.
LOW FUEL UNIT SHUTDOWN
ALARM ONLY
UNIT SHUTDOWN = The unit will be shutdown and
alarm if level reaches 15%.
ALARM ONLY = An alarm will be generated if level
reaches 15% and the engine will continue to run.
FUEL HEATER NOT INSTALLED
INSTALLED
NOT INSTALLED = A Fuel Heater is not installed.
INSTALLED = A Fuel Heater is installed.
MAX THROTTLE POSITION 80 − 125
120 default
IF THIS CONFIGURATION IS AVAILABLE, USE
FACTORY DEFAULT ONLY, DO NOT OPERATE
WITH A DIFFERENT SETTING.
EES SYSTEM INSTALLED (DPF
Installed)
Not Installed
Installed
Indicates if Diesel Particulate Filter is installed.
ALARM SETTINGS
OUT OF RANGE SHUTDOWN YES / NO YES = When the refrigerated compartment tempera-
ture has been out-of-range for 45 minutes, the alarm
light will come on, and the unit will shut down.
NO = When the refrigerated compartment tempera-
ture has been out-of-range for 45 minutes, the alarm
light will come on and the unit will continue to run.
Refer to 00053 BOX TEMP OUT-OF-RANGE for
more information.
RPM ALARM SHUTDOWN YES / NO YES = When the 00039 CHECK ENGINE RPM
alarm is activated the alarm light will illuminate and
the engine will shut down.
NO = When the 00039 CHECK ENGINE RPM alarm
is activated the alarm light will illuminate and the en-
gine will continue to run.
Table 5–1 Configuration Settings
(Refer to Section 5.2.3 for instructions on entering Configuration settings)
Configuration Selections Description
To Next Page
