6–3 62-11640
PRESTRIP STOPPED BY USER Pretrip has been stopped by user.
PRODUCTSHIELD: ECONO ON The unit is operating in ProductShield Econo which overrides normal
unit Start−Stop or Continuous Run operation. Refer to Section 4.10.3.
PRODUCTSHIELD: HIGH AIR ON The unit is operating in ProductShield High Air which overrides normal
unit speed operation. Refer to Section 4.10.3.
PRODUCTSHIELD: WINTER ON The unit is operating in ProductShield Winter which overrides normal
unit operation. Refer to Section 4.10.3.
RECORDING DATA − PLEASE WAIT
MICRO WILL RESTART WHEN
COMPLETE
This message will be displayed when the unit is starting and the
main microprocessor is completing communicating with another
module.
RECOVER / LEAK CHK / EVAC MODE This message will be displayed when the unit is in Service Mode
and the system is ready for recovery and leak testing.
REMOTE SWITCH 1 OPEN Remote switch is open. May be connected to a refrigerated
compartment door or a remote control switch.
REMOTE SWITCH 1 OPEN − LOW
SPEED
Shows that the remote switch is open and that the unit is running in
low speed. Switch may be connected to a refrigerated compartment
door or a remote control switch.
SERVICE MODE Selection which is used when servicing the refrigeration system.
Refer to Section 5.2.5.
SETPOINT CHANGED The new setpoint has been entered (saved into microprocessor
memory), the new setpoint will be used.
SETPOINT NOT CHANGED The new setpoint has NOT been entered (NOT saved into micropro-
cessor memory), the old setpoint will be used.
SETTING SMV: XXX % The START/RUN−OFF switch has been toggled out of the OFF
position and the CSMV is opening.
SLEEP MODE, OFF / ON TO WAKE The unit is cycled off in Sleep Mode. Place the START/RUN−OFF
switch in the OFF position, then back to the START/RUN position
to wake the microprocessor up.
SLEEP WARNING: DOOR OPEN The unit is configured for Rail Mode and the unit is in Sleep Mode
and a refrigerated compartment door is open. The unit will start as
needed for Sleep Mode.
SLEEP WARNING: NO TEMP CONTROL The unit is running in Sleep Mode to charge the battery and (in
Engine Operation) warm the engine coolant. It is not running to
provide temperature control.
SLEEP WARNING: REMS1(2) OPEN The unit is configured for Rail Mode and the unit is in Sleep Mode
and a remote switch is open. The switch may be connected to a
refrigerated compartment door or to a remote control switch. The
unit will start as needed for Sleep Mode.
SMV CLOSING: WAIT XXX SECONDS Power Up and the CSMV is closing. XX indicates the number of
seconds remaining until valve is fully closed.
START STOP LOCKED The setpoint has been locked into Start−Stop Operation. Continuous
Run can not be selected.
START−STOP MODE SELECTED Start−Stop Operation has been selected.
STATUS OK The unit is operating correctly.
Table 6–1 MessageCenter Messages
Message Description
