9-ACCESSORIES
Hydraulicconnections
Thetwostopvalvesarelocatedoneachsideofthearmtoallowproperandsafeconnectionoftheattachment
hydrauliclinestotherstauxiliaryhydrauliccircuit.
SMIL18MEX0849FA4
Open(A1)/Close(A2)toolofthestopvalve
19mmwrench
Hydraulicconnection(B)G3/8”maleportwithcap
Deliverypressure
Left-handhose
DischargepressureRight-handhose
NOTICE:alwayskeepeachconnectinghoseonthesamesideofthearm.Nevercross-overtheconnectinghoses
betweenthetwosidesofthearm.
Operationalsettings
Theowrate/pressurecharacteristicoftherstauxiliaryhydrauliccircuitissetbymeanstheenginepowerapplied.
Therstauxiliaryspecicationsforbreakeraresetfromfactory:
maximumowrate(P2+P3)30L/min(7.9USgpm)
maximumoperatingpressure(P3)170bar(2465psi)
