CASE CONSTRUCTION CX17C - Page 211

9-ACCESSORIES
Advisedmodels
NOTICE:allattachmentshownonthismanualareexclusivetotheNorthAmericanMarket.Toallothermarkets
contactyourauthorizedCASECONSTRUCTIONdealer,beforepurchasinganattachment.
NOTE:contactyourauthorizedCASECONSTRUCTIONdealer,beforepurchasinganattachment.
Hydraulicbreaker
ModelUnitweight
(withchisel
-without
adapter
plate)
Operating
pressure
Operating
ow
CH-1M
hydraulic
hammer(*)
97kg
(214lb)
60–130bar
(870–
1885psi)
20–30L/
min(5.3–
7.9USgpm)
CH-2M
hydraulic
hammer
147kg
(324lb)
60–130bar
(870–
1885psi)
20–30L/
min(5.3–
7.9USgpm)
NOTE:maximumtool(chisels)allowableformodel
CH-1M:6kg(13lb)
NOTE:maximumtool(chisels)allowableformodel
CH-2M:7kg(15lb)
NOTE:(*)pinsareincluded.
NOTICE:toimprovebreakingperformanceandstabilityit
ismandatorytouseadditionalcounterweight.
SMIL17MEX2784AA17
Adapterplate
ModelUnitweight
Klactype
48kg(106lb)
NOTE:forKlaccouplerapplicationsonly.
NOTE:pinbushingkitsnotrequiredforthisapplication.
SMIL17MEX2840AA18
Pin,bushingandinsertkit
Unitweight
14kg(31lb)
NOTE:useonlywithCH-2Mhydraulichammer.
SMIL17MEX2838AA19
9-11
