3.Pullthewrenchhandletoextractthelockingplate,until
itlatchesinplace.
4.Removethereleasetool,andstoreitinacompartment
ofthemachine.
5.Alignthearm(3)sothatisparalleltothebucket(4),
thenengagethepins(5)thatsecurethequickcoupler
tothebuckethooks.
NOTE:thebucketcylinder(6)mustbecompletelyre-
tracted:theangle(B)betweenthequickcouplerand
thebucketjawmustbeatleast100°.
SMIL16MEX3212AB3
Thebucketmayhitcab,canopy,boomandboomcylin-
derswhenitreachesvicinityofthem.
SMIL19MEX0855AA4
NOTICE:completethebucketengagementbyposition-
ingtheengagementpinsfullyinthehooksoftheadapter
plate.Donotengagethebucket,asshowninthegure
opposite,unlessthepinsarecompletelyinplace(detail
A);doingsomaycausethepinstobendunderstress,
alsoseriouslydamagingthequick-couplingsystemand
attachment.
SMIL17MEX0078AA5
