9-ACCESSORIES

WARNING

Crushinghazard!

Thisoperationmaybedangerous.Youaread-

visedtowearsuitableclothingandrespectall

relevantsafetymessages.

Failuretocomplycouldresultindeathorse-

riousinjury.

W0283A

6.Liftthebuckettoaheightof50cm(19.7in)(C)from

thegroundandengagetheright-handcontrolleverto

extendthebucketcylinder(6).Thebucketmakesthe

distinctivenoisewhenlocked.

SMIL16MEX3213BB6

9-23
