3.Extendthebucketcylinder(curlin)untiltherearpinof
theattachmentisrmlyseatedinthecoupler.
4.Stoptheengineandgetoutofthemachine.
SMIL17MEX2814AA2
5.Insertthereleasebar(3)androtatethelockinghooks
upwardsslightly.
6.Removetheretainerpin(4)andthelockingpin(2).
SMIL17MEX2815AA3
7.Usethereleasebar(3)torotatethelockinghook
downwardtoengagetheattachmentrearpin.
8.Installthelockingpin(2)andtheretainerpin(4).
9.Removethereleasebarfromitsseat.
SMIL17MEX2816AA4
