Attachmentdisengagement
WARNING
Misusehazard!
Followtheoperatinginstructionsinthischap-
ter.Anyotherpracticethathasnotreceived
thepriorapprovalofthemanufactureriscon-
sideredtobestrictlyforbidden.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0281A
WARNING
Impactandcrushinghazard!
Theattachmentcanswingfromonesidedur-
ingtheremovalprocedure.Keepclearofthe
attachment,includingtheswingarea.
Failuretocomplycouldresultindeathorse-
riousinjury.
W1492A
Todisengagetheattachmentfromthequickcoupling
system:
1.Lowertheattachmenttothegroundandstoptheen-
gine.
2.Removetheretainerpin(4).
3.Insertthereleasebar(3)intoitsseatandrotateitup-
wardsslightlytoremovethelockingpin(2).
SMIL17MEX2817AA5
4.Usethereleasebar(3)torotatethelockinghookup-
wardstotheunlockposition.
SMIL17MEX2818AA6
