Case 2050M - Direction Control Lever

4-OPERATINGINSTRUCTIONS
Directioncontrollever
WARNING
IMPROPEROPERATIONOFTHISMACHINECANCAUSEDEATHORSERIOUSINJURY.
MAKESURETHATEVERYOPERATOR:
-learnsandpracticesthesafeuseofmachinecontrolsinasafe,clearareabeforeoperatingthema-
chineonajobsite.
-clearstheworkareaofallbystanders.
-observespertinentlawsandregulations.
-followstheinstructionsinthisoperator'smanual.
Failuretocomplycouldresultindeathorseriousinjury.
W0189A
Controlthedriveandsteeringwiththedirectioncontrol
lever.Thedirectioncontrolleversendsanelectronicsig-
naltothecontroller.
Thedirectionalcontrolleverhasadetentintheneutral,
forward,andreversepositions.Theleverwillstayinthe
forwardorreversepositionuntilyouremoveitfromeither
detent.Atstartup,thecrawlermustbeintheneutralpo-
sitionforseveralsecondsbeforethemachinewillmove.
Thedirectionalcontrolleverpositionwillbedisplayedon
theinstrumentgauge.
Thesensitivityorfeelofthedirectioncontrollevercanbe
adjustedtomoderate,smooth,oraggressive.
RAPH12DOZ0080AA1
Directioncontrollever
RAPH12DOZ0149AA2
Movethedirectioncontrollevertothepositiondesired
(forward-neutral-reverse)andverifytheselectiononthe
multi-functiondisplay(neutralshown).
NOTE:Thecrawlerwillnotmoveunlesstheenginespeed
isaboveapproximately1200RPM.
Turnthecrawlerbymovingthedirectioncontrolleverin
thedirectiondesired.Turningisaccomplishedthrough
forwardorreverseonly.Movingthecontrolleverleftor
rightwithoutbeinginforwardorreversewillnotmovethe
crawler.
RAIL12DOZ0224AA3
4-13
