Case 2050M - Drive Belt

7-MAINTENANCE
Drivebelt
WARNING
Entanglementhazard!
Alwaysstoptheengineandengagetheparkingbrake,unlessotherwiseinstructedinthismanual,
beforecheckingand/oradjustinganydrivebeltorchain.
Failuretocomplycouldresultindeathorseriousinjury.
W0097A
WARNING
Movingparts!
Installallcovers,panels,andguardsafterservicingorcleaningthemachine.Neveroperatethema-
chinewithcovers,panels,orguardsremoved.
Failuretocomplycouldresultindeathorseriousinjury.
W0135A
Replacethedrivebeltwhenthehourmeterregisters1500hours.Checkthebeltvisuallyeachdayatthedailywalk
aroundforcorrecttension,wear,anddamage.Wrongbelttensionmaycausebatterychargefailure,engineover-
heating,ordrivebeltwear.
Prioroperation:
Keepallunauthorizedpersonnelclearofthearea.Parkthemachineonlevelground,inneutralwiththeparking
brakeapplied,andtheattachmentloweredtotheground.Makesurethatallresidualpressureisrelievedfromcircuits
beforebeginningmaintenance.
MaintenanceSpecications
VisualcheckEvery10hoursoreveryday
ReplacebeltsEvery1500hours
NOTICE:Iftheenginerunswiththedrivebeltloose,thedrivebeltcanslipandcausetheenginetooverheatorthe
batterytoreceiveinsufcientcharge.
Replacingthedrivebelt
1.TurnthemasterdisconnectOFF.
2.Locatethedrivebelt.
RAIL12DOZ034AA1
7-73
