Case 2050M - Overhead Controls; Climate Control System

3-CONTROLSANDINSTRUMENTS
OVERHEADCONTROLS
Climatecontrolsystem
Operatingtheclimatecontrolsystem
Theclimatecontrolpanelislocatedontheupperfrontcab
frameabovetheoperator’shead.
•
Fancontrol
Setthefour-speedfanatthedesiredcomfortsetting.
Turnthefancontrolknob(1)inonestepincrements
clockwisetoincreasefanspeed.Turnthefancontrol
knob(1)tothe12o’clockpositionforOFF .
•
Heatandairconditioningcontrol
Theheatandair-conditioningcontrolknob(2)hasthree
positions.OFFisthefarleftposition.Turntheheat
andair-conditioningcontrolknob(2)clockwisetothe
nextpositionforheat(straightup).Turntheheatand
air-conditioningcontrolknob(2)tothefarrightindicated
bythesnowakeforair-conditioning.
•
Temperaturecontrol
Usethetemperaturecontrolknob(3)toadjusttothede-
siredcabtemperature.Bluemarkingsindicatecooler
temperatures.Redmarkingsindicatewarmertemper-
atureswhenusingtheheater.Theheatandair-condi-
tioningknob(2)turnthesefunctionsonandoff.
RAPH12DOZ0083AA1
NOTICE:Ifyourmachineisequippedwithawatershut-offvalve,itshouldbeleftONforalltemperatureoperating
conditions.
3-39
