Case 2050M - Cab Air Louvers

3-CONTROLSANDINSTRUMENTS
Cabairlouvers
Mainairlouvers
Louversontheright-handcabsupportandleft-handcab
supportdirectairtowardthewindowsortheoperator.
Adjustmentscanbemadetodirecttheairowofthelou-
vers.
RAPH12DOZ0087AA1
Otherlouversarelocatedonthelowercontrolhousing.
RAPH12DOZ0086AA2
Recirculationairlouverandrearlouvers
Thereardeckhastwoclimatecontrollouvers(1).The
cabairlter(2)islocatedbehindtheoperator’sseatnext
totheoor.Whenthelouversareopen,airrecirculatesin
thecab.
NOTE:Alwayshavetheselouversopenformaximum
coolingwiththeairconditioningormaximumheatwiththe
heater.
RAPH12DOZ0074AA3
3-40
