Case 2050M - Machine specifications and dimensions

8-SPECIFICATIONS
Machinespecicationsanddimensions
RAIL14DOZ0570FA1
Heightandgroundclearancedimensions
PATmodelsBDmodels
LT
XLT/WT
LT
WT/LGP
A-T opofexhauststack
2876.6mm
(113.3in)
2876.6mm
(113.3in)
2876.6mm
(113.3in)
2876.6mm
(113.3in)
B-Bladeheight1369mm
(53.9in)
1369mm
(53.9in)
1108mm
(43.6in)
1108mm
(43.6in)
C1-Groundclearanceatbellypans
(lowest)
325mm
(12.8in)
325mm
(12.8in)
325mm
(12.8in)
325mm
(12.8in)
C2Groundclearanceatdrawbar
525.2mm
(20.7in)
525.2mm
(20.7in)
525.2mm
(20.7in)
525.2mm
(20.7in)
C3-Centerlineofdrawbaropening
601.1mm
(23.7in)
601.1mm
(23.7in)
601.1mm
(23.7in)
601.1mm
(23.7in)
D-Shankheight(transportposition)
(**)
556.6mm
(21.9in)
556.6mm
(21.9in)
556.6mm
(21.9in)
556.6mm
(21.9in)
E-T opofseatheadrest
2553.7mm
(100.5in)
2553.7mm
(100.5in)
2553.7mm
(100.5in)
2553.7mm
(100.5in)
F1-Heightofcabwithairconditioner
3103.4mm
(122.2in)
3103.4mm
(122.2in)
3103.4mm
(122.2in)
3103.4mm
(122.2in)
NOTE:(1)Groundclearanceandoverallheightdimensionsarewiththegrouserfullypenetrated.Add55.5mm
(2.2in)ifthemachineisonasolidsurface.
NOTE:(**)Rippertransportwithshankinthemid-rangeposition.
