Case 2050M - Page 277

8-SPECIFICATIONS
RAIL14DOZ0571FA2
Lengthdimensionswithbladestraight
PATmodelsBDmodels
LT
XLT/WTLT/XLTWT/LGP
A-Overalllength:
Noblade,norearequipment,CLTchain
3840.5mm
(151.2in)
4345.7mm
(171.1in)
3840.5mm
(151.2in)
4345.7mm
(171.1in)
B-Overalllength:
Bladestraight,norearequipment
5308.5mm
(209.0in)
5738.6mm
(225.9in)
5200.1mm
(204.7in)
5731.3mm
(225.6in)
C-Overalllength:
Bladestraight,withdrawbar
5491.5mm
(216.2in)
5902mm
(232.4in)
5387.0mm
(212.1in)
5894.7mm
(232.1in)
D-Overalllength:
Bladestraight,withripper
6974.3mm
(274.6in)
7383.8mm
(290.7in)
6869.7mm
(270.5in)
6982.6mm
(274.9in)
NOTE:AlldimensionsusetheCASELubricatedTrackchain(CLT).
NOTE:Overalllengthiswiththebladepitchat55%.
8-7
