Case 2050M - Left-Hand Side Controls; Control Levers

3-CONTROLSANDINSTRUMENTS
LEFT-HANDSIDECONTROLS
Controllevers
WARNING
Hazardtobystanders!
Alwayssoundthehornbeforestartingthemachine.Makesuretheworkareaisclearofotherpersons,
domesticanimals,tools,etc.beforeyouoperatethemachine.Neverallowanyoneintheworkarea
duringmachineoperation.
Failuretocomplycouldresultindeathorseriousinjury.
W0304A
Hornbutton
Thedirectioncontrolleverallowsfordirectionalmove-
mentofthemachine.Thehornbuttonisalsolocatedon
thedirectioncontrollever.Alwayssoundthehornbefore
startingthemachine.
RAIL12DOZ0181AA1
Directioncontrollever
Thedirectioncontrollever(1)allowsforward,reverse,
neutraldirection,turningandcounterrotation.
Theleverhasdetentpositionsforneutral,forward,and
reverse.Theleverremainsintheforwardorreversepo-
sitionuntilitismovedbytheoperator.Turningisalsocon-
trolledbythedirectioncontrollever.Thedirectioncontrol
leverhasafeelpointforleftandrightcounterrotation.
Usethemachineinaclear,unobstructedareauntilyou
becomefamiliarwiththecontrols.Seepage4-10forad-
ditionalinformationonoperatingthemachine.
RAPH12DOZ0080AA2
3-30
