3-CONTROLSANDINSTRUMENTS

Footcontrols

Dualfunctionpedal

Thedualfunctionpedalcanbeswitchedtooperateasadecelerationpedaloratransmissioncontrolpedal.Asa

decelerationpedal,theengineRPMisreducedasthepedalisdepressed.Asatransmissionpedal,thehydraulic

systemisde-strokedasthepedalisdepressed.Thetransmissionpedalisthedefaultfunction.Thesesettingsare

madethroughthetransmissionselectiononthemulti-functiondisplay.

NOTE:Seethemulti-functiondisplayonpage4-20formoreinformation.

Transmissionpedal

Asatransmissionpedal,themachinevariesthetransmis-

sionow(pump/motordisplacement)allowingforinching.

Pushingthepedalcompletelydownwillde-strokethehy-

draulics.

RAIL13DOZ1264AA1

Decelerationpedal

ThedecelerationpedalreducestheengineRPMand

slowsthemachine.Pushthedecelerationpedaltoslow

orstopthemachine.

RAIL12DOZ1254AA2

Usethedecelerationpedaltoreducethespeedallthe

waytozerobyde-strokingthegrounddrivealongwith

decreasingtheengineRPM.

NOTE:Usethedecelerationpedaltocontrolthedozerfor

precisionwork.

474495663

3-8
