Case 2050M - Operators Seat

3-CONTROLSANDINSTRUMENTS
OPERATOR'SSEAT
Operator'sseat
WARNING
Lossofcontrolhazard!
DONOTmakeseatadjustmentswhilethemachineisinmotion.Allseatadjustmentshouldbemade
withthemachinestationaryandtheparkingbrakeapplied.
Failuretocomplycouldresultindeathorseriousinjury.
W0293A
Cabmachinesareequippedwithclothairsuspensionseats.Adjusttheseatsothatyoucanfullydepressthede-
celerationortransmissionpedalwhenyourbackisagainsttheseatbackrest.Adjustmentsforallstylesofseatsare
similar.
Lumbaradjustment
Locatethelumbaradjustmentknobonthebackoftheop-
erator’sseat.Turntheknobclockwisetoincreasethe
lumbarsupport.Turntheknobcounterclockwisetode-
creasethelumbarsupport.
RAIL12DOZ0548AA1
Backrestadjustment
Thebackrestadjustmentislocatedontheleft-handside
oftheoperator’sseat.T oadjustthebackrestliftuponthe
handle,movethebackresttothedesiredposition,and
releasethehandle.Tilttheseatbackcompletelyforward
toaccessthecabairlterandoperator’smanualstorage
pocket.
RAIL12DOZ0650AA2
3-4
