Case 2050M - Work Lights

To Next Page

To Previous Page

7-MAINTENANCE

Worklights

1.T oreplaceworklights,removethePhillipsscrewsfrom

thefrontofthelight.

RAPH12DOZ0104AA1

2.Disconnectpushonconnectors,andreplacethelamp

assembly.Pushtheconnectorson,makingcertain

connectionsarermlyinplace.

3.Replacethelampassembly,andsecuretheframewith

thePhillipsscrews.

RAIL12DOZ0196AA2

7-106
