Case 2050M - Tracks - General Specification

8-SPECIFICATIONS
Tracks-Generalspecication
TrackadjustmentHydraulic
TrackframesuspensionPivotshaftandoscillatingequalizerbeam
Tracklinkpitch
203.2mm(8.0in)
Heightoftrackshoegrouser71.5mm(2.8in)
Trackpindiameter
44.53mm(1.753in)
Trackbushingdiameter
*72.7mm(2.862in)or**93.2mm(3.67in)
Numberofsprocketteeth*25total(Five5toothsegments)or**13
Sprocketpitchdiameter*814.97mm(32.09in)or**846.42mm(33.324in)
TrackframeReinforcedboxedsectionswithreplaceableslopedtrackcovers
CASElubricatedtrack(CLT)Standard
CASEextendedlifetrack(CELT)Optional
NOTE:IfmachineisequippedwithoptionalCELTchaingroundpressurewillbe0.7kPa(0.1psi)greater.
LT=LongTrack
XLT=ExtraLongTrack
WT=WideTrack
LGP=LowGroundPressure
Tractormodels
LTXLT
WT/LGP
Numberoftrackshoesperside
404545
Numberofcarrierrollersperside
222
Numberoftrackrollersperside
7
88
Rollerangecongurationfrom
sprocket
SF,DF ,SF ,DF ,SF,DFSFSF,DF ,SF ,DF ,SF,DFSFSF,DF ,SF ,DF ,SF,DFSF
Carrierrollerdiameter
187.5mm
(7.38in)
187.5mm
(7.38in)
187.5mm
(7.38in)
Trackrollerraildiameter210mm
(8.27in)
210mm
(8.27in)
210mm
(8.27in)
Idlerraildiameter678mm
(26.69in)
678mm
(26.69in)
678mm
(26.69in)
Lengthoftrackongroundmodel—
CASELubricatedTrack(CLT)
2645mm
(104in)
3277mm
(129in)
3277mm
(129in)
Lengthoftrackongroundmodelwith
optionalCASEExtendedLifeTrack
(CELT)
2624mm
(103in)
3251mm
(128in)
3251mm
(128in)
Trackgauge1941mm
(76in)
1941mm
(76in)
2261mm
(89in)
610mm
(24in)
610mm
(24in)
711mm
(28in)
—
711mm
(28in)
762mm
(30in)
Trackshoewidthoptions
——
914mm
(36in)
8-4
