6-WORKINGOPERATIONS
Bulldozerblade—Pushbeamcentering
1.Setthebulldozerbladeonalevelsurface.Makesure
thebladeisevenwhenitrestsontheground.
2.Raisethebladeslightlyofftheground.
RAIL14DOZ0525AA9
3.Removethebolts(A),(B)frombothendsoftheleft-
hand(C)andright-hand(D)turnbucklestoallowmove-
mentoftheturnbucklebody(E).
RAPH15DOZ0008BA10
4.Extendtheleft-handturnbuckle(C)(rotate1/2turn)
counter-clockwisewhenpositionedbehindtheblade
asshown.Extendtheright-handturnbuckle(rotate
1/2turn)counter-clockwisewhenpositionedbehindthe
blade.Continuetoalternatelyturneachturnbuckleun-
tilbothturnbucklesaretight.
RAIL14DOZ0529AA11
