7-MAINTENANCE

Releasingpressureinthehydraulicsystem

1.Parkthemachineonrm,levelground,lowertheat-

tachmentstotheground,andstoptheengine.Setthe

parkbrake.

2.Keepallunauthorizedpersonnelclearofthemachine.

TurntheignitionswitchkeytotheONposition.Donot

starttheengine.

3.Pressandreleasetheimplementenable/disable

switchtoenablethemachinehydraulics.Whenthe

functionison,aLEDindicatorwillappearonthe

console.

4.Operatethecontrolleversfromrighttoleftandfront

torearapproximatelyadozentimes.Turntheignition

keytotheOFFposition.

RAPH12DOZ0079AA1

RAPH12DOZ0081AA2

7-12
