7-MAINTENANCE

11.Filltheenginewiththeproperamountofoilthrough

thellport(4).

12.Starttheengineandrunatidlespeed.Checkthe

engineoillterandremotedrainforleaks.

13.Aftertwominutesstoptheengine.

14.Waitfortheengineoiltodraindownforanaccurate

readingonthedipstick(1).

RAIL13DOZ1693AA6

15.Checkthedipstick(1),andaddadditionaloil,ifnec-

essary.

16.Checkforleaksaroundthelteranddrain.

17.Securethelowerengineaccessplate.

RAIL13DOZ1694AA7

NOTE:Theoilowratecanbeimprovediftheoilisslightlywarmandtheoilllcapordipstickisremovedfromthe

enginewhiledraining.

7-47
