7-MAINTENANCE

4.Slidethelargelterelementtowardthefrontofthe

machine,thenpullbackslightlytodisengagethelter

elementfromtheaircleanerhousing.Removethelter

elementanddisposeofproperly.

RAIL13DOZ0782AA4

5.Graspthehandleofthesecondarylterelementinside

theaircleanerhousingandseparatethelterfromthe

housinganddiscard.

RAIL13DOZ0784AA5

6.Cleananydebristhatmayhaveaccumulatedintheair

cleanerhousingandcheckforanydamage.

RAIL13DOZ0788AA6

7.Insertthesmallerlterelementinsidetheaircleaner

housing.

RAIL13DOZ0785AA7

7-84
