7-MAINTENANCE
3.Removetheboltfromtherippershankcover,andturn
thecoverfromthedetent.Removethespringand
punchoutthebolt.
RAIL13DOZ1268AA3
Adjustingtherippershanks
4.Removethebolt.Theplatebeneaththebolthasa
detenttoholdthepininplace(1).
5.Drivethepin(2)out,andadjusttheshanktotheposi-
tiondesired.
NOTE:Therippershankshaveathreadedoricetoinsert
anI-bolttoaidinlifting.Rippershanksareheavy.Use
appropriateliftingequipment.
6.Replacethepinandretainingclip.
RAIL13DOZ1268AA4
Ripperteeth
1.Damagedripperteethcanbereplacedwithoutremov-
ingtherippershank.
2.Positiontheripperteethslightlyabovetheground.Re-
movecapandpunchoutbolt.
3.Cleanmatingsurfacesandreplacerippertoothwitha
newcomponent.Replacebolt.
Rearattachmenttorquevalues
Ripper
705-1165N·m(520.0-859.3lbft)
Drawbar
705-1165N·m(520.0-859.3lbft)
Hitch
430-485N·m(317.2-357.7lbft)
7-99
