3-CONTROLSANDINSTRUMENTS
Criticalwarnings
Thefollowingtablelistscriticalwarningdisplaysthatmayappearontheinstrumentclusterandthecorrectiveaction
required.Shouldafaultoccur,acontinuousaudiblealarmwillsound,andthestopmasterIndicatorwillbeRED.A
warningmessagewillbedisplayedinthemessagearea.
Stopmasterindicator(Red-critical)
ThestopmasterIndicatorisacritical
warningdisplay.Whenthestopmaster
indicatorilluminates,IMMEDIATELYbring
themachinesafelytoastop,andturnthe
engineOFF .
WARNING
Damagedcomponentscancauseavehicleac-
cident.
IftheSTOPmasterindicatorilluminates,im-
mediatelyandsafelybringthemachinetoa
stopandturntheengineoff.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0050A
RAIL12DOZ0821AA3
Display
Description
CorrectiveAction
Engineoil
pressure
Lowengineoil
pressure
Bringthemachinetoasafestop,andturntheengineOFFimmediately.
Contactyourdealer.
Brake
pressure
Lowbrakepressure
Bringthemachinetoasafestop,andturntheengineOFFimmediately.
Contactyourdealer.
Coolant
temperature
Highenginecoolant
temperature
Bringthemachinetoasafestop,andturntheengineOFFimmediately.
Checkthecoolantlevelsafterallowingtheengineandthecoolanttocool.
Contactyourdealer.
Hydraulicoil
temperature
Highhydraulicoil
temperature
Bringthemachinetoasafestop,andturntheengineOFFimmediately.
Contactyourdealer.
DEFtank
empty
DEFlevelbelow
minimumacceptable
level
RelltheDEFtankimmediately.
DEFinjection
failed.
Technicalfailure
detected
Ifmachinecontinuestooperateforover5hours,theenginemaystop.
Contactyourdealer.
SCRfailure
SCRfault/failure
detected.Lossof
power.
Contactyourauthorizeddealerforrepair.
3-15
