Case 2050M - Page 76

3-CONTROLSANDINSTRUMENTS
2.Fanreverseswitch
Thisisathree-positionswitch.Tousethemanualfanreverse,placethemachineinneutralatidle
speed.Depressthemanualfanreverseswitchanddepressthethrottletohighidleforaminimum
of10secondsoruntildebrisstopsblowingoutofthecoolers.Returnthemachinetoidleand
releasethemanualfanreverseswitch.Presstheupperpartoftheswitchforthemanualmomentary
reversalasdescribed.Thecenterpositionoftheswitchistheautomaticposition,andthelower
positiondisablestheautomaticfan.Leavingtheswitchintheautomaticpositionisrecommended
inheavydebrisconditions.
3.Frontheadlampswitch
Pushonthetopoftheswitchforfrontworklights.Pushingonthebottomoftheswitchwillturn
thelightsOFF.
4.Rearlampswitch
Pushonthetopoftheswitchforrearworklights.Pushingonthebottomoftheswitchwillturn
thelightsOFF.
5.Left-hand/Right-handwiper/washerswitch
A.PushswitchtothecenterpositionforON.
B.Pushonthefrontofswitchforwasheruid.
6.Front/Rearwiper/washerswitch
A.PushswitchtothecenterpositionforON.
B.Pushonthefrontofswitchforwasheruid.
7.Enter/Escapeswitch
Usethisswitchtomakeselectionsonthemonitormulti-functiondisplay.Seepage3-44forfurther
information.
8.Up/Downswitch
Usethisswitchtoscrollbetweenselectionsonthemonitormulti-functiondisplay.Pushthe
topofswitchforup.Pushthebottomoftheswitchtoscrolldown.SeepageNavigatingthe
multi-functiondisplayscreenforfurtherinformation.
9.Implementenable/disableswitch
Pressandreleasetheimplementenableswitchtoenablethemachinehydraulics.Theswitchisa
momentaryswitch.Themachinedefaultstohydraulicsoffuponkeyon.Thekeymustbeinthe
onpositionwhiletheengineisnotcrankingtousetheimplementenable/disableswitch.Whenthe
functionison,aLEDindicationwillappearontheconsole.
3-28
