SECTION 58 -- ATTACHMENTS AND HEADERS -- CHAPTER 2
58-26
6. Use the lift cylinder and tractor 3 point hitch to
carefully lift the bevel gearbox and canopy sup-
port away from the cutterbar.
NOTE: The flotation system must be engaged to en-
sure the bevel gearbox lifts up off the lower drive
module.
600-5-1
58
7. Finish loosening the the tie bolts, and slide the
lower drive module away from the cutter bar.
600-5-2
59
