14.2 Coins dispenser
The coins dispenser performs coins storage and dispensation functions.
Frontal view
1. Coins entry
2. Coins exit
3. Leds of status
4. Security locker (optional)
5. Unblocking
14.3 Coins Cassette / Stacker
The coin cassette is the final deposit of the coins where they are kept until they are
withdrawn. Cassette removal is locked with a security key.
The coin cassette allows:
• Remove leftovers from the dispenser in bulk in a single
action, without having to make a withdrawal and collect
the coins in the exit tray.
• Empty the dispenser for maintenance.
Internal view and Devices | 64
