Casio G'z One

Getting Started with Your Phone
2. Insert the tip of the corner of
the Device Lock Tool marked
with the battery lock icon
into
the groove of the screw type
battery lock and rotate in the
direction indicated by the arrow
in the illustration to the left.
Rotate the battery lock as far
as it will go towards the LOCK
position.
k Removing the Battery
1. Insert the tip of the corner of
the Device Lock Tool marked
with the battery lock icon
into
the groove of the screw type
battery lock and rotate in the
direction indicated by the arrow
in the illustration to the left.
Rotate the battery lock as far
as it will go towards the FREE
position.
2. Remove the battery by pulling
up on the tab.
WARNING!
Do not twist the battery as
shown in the illustration to the left. Doing
so can damage the phone and the battery.
1.
2.
19
