MATRIX X220 AC/DC wiring diagram
Wiring diagram legend
CA Power supply connector 230V 50/60Hz
CD 6 Manual remote control
CP EMC capacitors
CR Power supply connector for the cooling system
CRS 14-pole connector for simple automation
CT 6-pole connector
D Secondary diode
DB “Dual Boost Chopper” IGBT
DW “DOWN” button
EVG Gas solenoid valve
F Fuse
FCTA Torch button filter board
FE Primary circuit EMC filter
FHF HF filter
FPP Torch / PEDAL potentiometer
FPS Pedal “ON” switch
HR Water cooling system
IL Power supply switch
L Inductor
L1-L2 PFC inductances
M Electric pump
MI “Full Bridge” IGBT
MIS Secondary IGBT circuit
MV Fan motor
PD Remote control potentiometer
PSR7 Pedal
PT Torch button
RF Membrane keyboard
RP Primary rectifier
S-AI ROBOMAT-1 board
S-ANY ANY-BUS board
SD Secondary circuit diodes PCB
SHF High frequency (HF) PCB
SI Secondary circuit IGBT board
S-INT DIG Digital interface PCB
S-INV Inverter PCB
S-ISR Automation interface isolation board
S-NFC NFC communication card
S-TFT TFT display card
TC Current transducer
TF Toroidal ferrite
TH Secondary circuit diode thermostat
TH20 Coolant thermistor
THA Ambient thermistor
THD Heatsink thermistor
THF HF transformer
TORCH TIG torch
TORCH UP/DOWN 4 wires TIG UP / DOWN 4-wire version torch
TORCH UP/DOWN 5 wires TIG UP / DOWN 5-wire version torch
TORCH with potentiometer TIG torch with potentiometer
TP Transformer
UP “UP” button
USB USB socket
W Pressure switch
