Changing general welding parameter limits
The welding machine allows you to change the maximum and minimum limits for some welding parameters. This makes the welding
machine more expert and versatile.
To change the general welding parameter limits, go to the “CONFIGURATION” menu, and select the “WELDING” menu.
You can access the “CONFIGURATION” menu by:
• Holding down the SET key
for 5 seconds.
• By selecting the icon
from the process setting page.
• Select the “WELDING” menu.
CONFIGURATION
GENERAL
WELDING
INFORMATION
ERROR PAGE
PANEL LOCK
The parameters that can be changed as shown below, with the current default value and the high and low limits.
MAIN MENU MAIN SUB-MENU
PARAMETERS /
HIGH - LOW LIMIT
DEFAULT
VALUE
NOTE
WELDING
MAX PRE-GAS 1,0 s (1,0-2,50) 1,0 s Maximum settable PRE-GAS time limit
MAX SLOPE-UP 5,0 s (5,0-10,0) 5,0 s Maximum settable SLOPE-UP time limit
REMOTE FLOOR
5A (1-220) -
MATRIX X220
5A (1-300) -
MATRIX X300
5 A
Minimum settable remote control current limit.
WARNING: If the minimum limit setting (for the re-
mote control MINIMUM CURRENT) is greater than
or equal to the value for the I1 , MAIN welding CUR-
RENT, you will weld at the I1 , MAIN welding CUR-
RENT, irrespective of the setting you have chosen
on the remote control.
MAX SLOPE-DOWN 8,0 s (8,0-15,0) 8,0 s Maximum settable SLOPE-DOWN time limit
MAX POST-GAS 25,0 s (10,0-25,0) 25,0 s Maximum settable POST-GAS time limit
MAX SPOT 25,0 s (10,0-25,0) 25,0 s Maximum settable SPOT WELDING time limit
GAS TEST DURATION 15 s (5-60) 15 s Duration of the welding gas flow test.
The welding modes that can be started using the current default setting are shown below.
MAIN MENU MAIN SUB-MENU
PARAMETERS /
HIGH - LOW LIMIT
DEFAULT
VALUE
NOTE
WELDING
ANTI-STICK
ACTIVE X
Anti-sticking mode active or deactivated for all
processes
INACTIVE
AC START
POSITIVE X
AC ignition mode with positive or negative polarity
NEGATIVE
IGNITION
TIP-SIZE X
Automatic TIG ignition current regulation, based on
the electrode size chosen
MANUAL
Manual setting of the current and duration of the
ignition time
2T/4T AUTO ADV
INACTIVE X
Enabling 2/4 touch STANDARD or AUTO
ADVANCE
ACTIVE
REIGNITION
AT START UP X Automatic TIG arc reignition mode. It is possible
to choose enabling of automatic reignition within
the first 3 seconds of welding, automatic reignition
enabled throughout welding, or to disable
automatic reignition
ALWAYS ON
ALWAYS OFF
