CEA MATRIX X220 AC/DC - Hardware Test Menu

46
Hardware test menu
The hardware test menu allows you to test functioning of the gas solenoid valve, the fan, and the cooling unit.
To access this information go to the “CONFIGURATION” menu and select the “HW TEST” menu.
You can access the “CONFIGURATION” menu by:
• Holding down the SET key for 5 seconds.
• By selecting the icon
from the process setting page.
• Select the “HW TEST” menu.
CONFIGURATION
ERROR PAGE
PANEL LOCK
USB SAVE RESTORE DATA
DIAGNOSTIC
HW TEST
MAIN MENU MAIN SUB-MENU
PARAMETERS /
HIGH - LOW LIMIT
DEFAULT
VALUE
NOTE
HW TEST
GAS
OFF X
Service centre test.
Activates / Deactivates the gas solenoid valve
ON
FAN
OFF X
Service centre test.
Activates / Deactivates the fan
ON
COOLING
OFF X
Service centre test.
Activates / Deactivates the cooling system
ON
