Matrix X300 AC/DC wiring diagram
Legenda schema elettrico
CD 6 Manual remote control
CP EMC capacitors
CR Power supply connector for the cooling system
CRS 14-pole connector for simple automation
CT 6-pole connector
D Secondary diode
DS Secondary diode discharger
DW “DOWN” button
EVG Gas solenoid valve
F Fuse
FCTA Torch button filter board
FE Primary circuit EMC filter
FHF HF filter
FPP Torch / PEDAL potentiometer
FPS Pedal “ON” switch
HR Water cooling system
IL Power supply switch
M Electric pump
MI IGBT “Full Bridge”
MIS Secondary IGBT circuit
MV Fan motor
PD Remote control potentiometer
PSR7 Pedal
PT Torch button
RC Secondary R-C diode
RF Membrane keyboard
RP Primary rectifier
RSP Secondary IGBT protection board resistance
S-AI ROBOMAT-1 board
S-AL PCB
S-ANY ANY-BUS board
SDRV Secondary circuit PCB
SHF High frequency (HF) PCB
S-INT DIG Digital interface PCB
S-INV Inverter PCB
S-ISR Automation interface isolation board
S-NFC NFC communication card
SP Secondary IGBT protection board
SR Cooling system relay board
S-TFT TFT display card
TA Auxiliary transformer
TC Current transducer
TH20 Coolant thermistor
THA Ambient thermistor
THD Heatsink thermistor
THF HF transformer
THP Primary circuit thermistor
THS Secondary circuit thermostat
TORCH TIG torch
TORCH UP/DOWN 4 wires TIG UP / DOWN 4-wire version torch
TORCH UP/DOWN 5 wires TIG UP / DOWN 5-wire version torch
TORCH with potentiometer TIG torch with potentiometer
TP Transformer
UP “UP” button
USB USB socket
W Pressure switch
