24
Configuration with SLOW PULSE
5 3 6241
1. Peak current.
2. “Absolute” basic current value in Ampere (default) or as % of the peak current.
3. Duration of the peak current.
4. Duration of the basic current.
5. HOT START – Increases the welding current, on a percentage basis, for a time interval that can be set at the start of the welding
process, thereby reducing the risk of poor melting at the start of the joint.
6. ARC FORCE - Regulates the dynamic characteristics of the arc, in percentage terms.
NOTE: If the BACK
key is held down for 2 seconds, the parameter goes back to its default setting.
Once the all the selections/settings indicated above have been made, welding can begin.
During the welding process the display shows the current and the real voltage at which the operator is actually welding.
